Electronics Circuits Simulator

Learn electronic circuits in a new and exciting way and increase your understanding of basic electronic circuits.

Seven complete levels to assess your knowledge of basic electronic circuits including Series Parallel Resistor circuits, Resistor Capacitor (RC) filters, Graetz Bridges, Wheatstone bridges, Weighted summing amplifiers, Transistor switches and Oscillator circuits.

This game complements the Circuit Warz game which is also on STEAM. It allows you to practice each of the 7 levels before you play the main game.

Topics covered include

Current and Voltage
Resistance and Resistors
Capacitance and Capacitors
Alternating Current
Semiconductors
Transistors
Diodes
Ohms Law
Equivalent resistance
